Icon | Stage 2 | RXT Rear Suspension System | (2005-2023) Toyota Tacoma | K53162

Icon Stage 2 RXT Rear Suspension System, 2005-2023 Toyota Tacoma

K53162

Application:

2005-2023 Toyota Tacoma

Features and Benefits:

Icon RXT Multi-Rate Leaf Spring

• 3 user-adjustable spring rates for unique vehicle configurations
• Military wrap front eyelet for increased durability
• Galvanized leaf separators reduce friction and aid in corrosion resistance
• Leaf tip inserts reduce noise and increase ride comfort
• Potential for increased wheel travel when used with RXT shock (up to 20%) without sacrificing up-travel
• "ICON 1K" tested under rigorous off-road conditions to validate tune, performance, strength, and durability
• Direct bolt-in to OEM spring location makes for an easy insta

Icon RXT Rear Shock

• Corrosion resistant, one-piece impact extruded aluminum shock bodies with 7/8" shafts
• CDC Valve technology allows for 10 settings of quick and easy compression damping adjustment
• 10" aluminum reservoirs provide generous oil and nitrogen volume for consistent damping as shock temperature increases
• Shocks are fully rebuildable and revalveable
• Simple and straightforward installation
• Unique side-mounted lower eyelet allows for increased travel while utilizing factory mounting location
• Vehicle-specific tuned shocks provide increased damping and oil volume

Icon Hydraulic Rear Bump Stop Kit

• 2.5" travel bump stop reduces rear end 'kick' and improves overall performance
• Position sensitive technology exponentially increases bottom-out resistance
• Vehicle specific bump stop tune to provide smooth engagement and best ride quality
• Direct bolt-in to OEM bump stop location makes for an easy and straightforward install
• Heavy duty 1 ¼" CNC machined nitro steel shaft
• Multi-stage CAD plated body for maximum corrosion resistance
• Double sealed high pressure Schrader valve Operating range of 50 - 250 PSI
• Replaceable noise reducing striker pad
• Fully serviceable
• "ICON 1K" tested under rigorous off-road conditions to validate tune, performance, strength, and durability

Tech Info:

• OEM Wheels & Tires Fitment: Yes
• Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 4.75" Backspace / 0mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.00" Backspace / 0mm Offset
• Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.00" Backspace / 0mm Offset
• Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
• APPLICATION NOTE #17: These are stand-alone kits and are not to be used in conjunction with any other aftermarket kits
• APPLICATION NOTE #55: Shocks are fully serviceable. coilover heights indicated are for a stock equipped vehicle
• APPLICATION NOTE #87: Installation of complete ICON system required to attain advertised wheel travel. Use of any other manufacturers components will not provide advertised wheel travel and could cause unknown damage.
• TECH NOTE: Not compatible with 2005-2015 2WD 5-Lug Toyota Tacoma models
• TECH NOTE: Most Tacoma submodels withh have rear lift height range of 1.875-2.625", depending on rear spring configuration and rear weight
• TECH NOTE: 2017-2023 Tacoma TRD Pro models will have 1.375-2.125" of rear lift over stock, depending on rear spring configuration and rear weight

System Components:

• 56103 (QTY: 1) | 05-23 TACOMA REAR HYD BUMP STOP KIT
• 57826CP (QTY: 1) | 05-UP TACOMA RXT REAR 2.5 RR CDCV PAIR
• 158505 (QTY: 2) | 05-23 TACOMA MULTI RATE RXT LEAF PACK W/ ADD IN LEAF
• 52050 (QTY: 1) | TOYOTA REAR 8.0" U-BOLT KIT
