Icon | 2.5" VS Rear Shocks W/CDEV Dampening Adjustment Knobs | 22+ Tundra w/0-1.5" Rear Lift | 23+ Sequoia w/0-3" Rear Lift

Icon | 2.5" VS Rear Shocks W/CDEV Dampening Adjustment Knobs | 22+ Tundra w/0-1.5" Rear Lift | 23+ Sequoia w/0-3" Rear Lift

57840EP

FEATURES & BENEFITS:

• ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC)
• ICON's internal "Bump Zone" increases damping by 20% to provide more control as the shock approaches full compression
• Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
• One-piece, hard anodized, impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
• Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
• Nitrogen charged monotube design with remote reservoir
• One-piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
• 7/8" diameter induction hardened, chrome plated shock shaft
• PTFE lined spherical bearings and application specific mounting hardware
• 6061 aircraft grade aluminum CNC machined components
• Fully rebuildable and re-tunable

TECH INFO:

• TECH NOTE: Compatible with 0-1.5" of rear lift on non-TRD Tundras or 0-1" lift on TRD Tundras equipped with rear coil springs
• TECH NOTE: Compatible with 0-3" of rear lift on Tundras equipped with rear OE Load-leveling Rear Height Control Air Suspension
• TECH NOTE: Compatible with 0-3" of rear lift on 2023-2024 Sequoias equipped with rear coil springs
• TECH NOTE: If upgrading a vehicle equipped with Adaptive Variable Suspension (AVS) all other vehicle systems remain functional
• TECH NOTE: Also requires installation of IIC kit (Part # 53508) and CDEV front coilovers (Part # 58770E or 58775E)
